Premium Solar Shades 10 Percent Openness
These solar shades made with Phifer Sheerweave® fabrics are perfect for rooms where you need a combination of privacy and a clear view outside. Bacterial and fungal resistant, these shades are also C.P.S.C. certified and are safe for small children and animals.
Product Colors
Product Details & Features
Description
- Phifer Sheerweave® 4100 & 2360 fabrics
- High quality, durable vinyl coated fiberglass & polyester yarns
- 10% openness factor: UV blockage 90%
- Compare Openness Factors
- Made in the USA with domestic and foreign parts
- Greenguard® Certified
- Bacteria and fungal resistant fabric
- Choice of cordless spring loaded roller or continuous loop lift cord
- Minimizes heat and glare while maintaining view
- Durable and easy to maintain
- Suitable for residential or commercial applications
- Conforms with C.P.S.C. child safety guidelines
- Fit or Free™ Guarantee
- 60 Day Satisfaction Guarantee
- Limited Lifetime Warranty
Specifications
- Vinyl coated polyester and fiberglass yarns with 10% openness factor
- UV blockage: 90%
- Spring loaded roller or continuous loop lift cord
- Metal roller: 1 3/8" or 2 1/2" based on width and height ordered
- Standard or reverse roll available. Reverse roll is not available with the cassette valance.
- Continuous loop cord comes with nylon beaded cord in White, Vanilla, Grey or Black color coordinated to shade fabric specified; metal beaded chain available on request
- Metal hembar sewn into bottom of fabric
- Universal brackets for inside, outside or ceiling mounts
- Cassette valance available with the continuous cord loop lift system only for an additional charge. The cassette valance must be ordered with the original shades and cannot be added after the shades are made.
- Inside mount shades are made for brackets to be mounted inside window with a top window width equal to the size ordered. Fabric deductions vary based on size of shade and type of lift mechanism specified - from 7/8" to 1 3/8." Fabric and roller tube are made to same size
- Outside mount shades are manufactured to fit width ordered as bracket to bracket width. Fabric deductions vary based on size of shade and lift mechanism specified - from 7/8" to 1 3/8." Fabric and roller tube are made to same size
- Minimum width: 6" with chain; 18" with cordless spring roller
- Maximum width: standard shade - 144"; shade with cassette - 120"; shade with cordless spring roller - 72"
- Minimum height: 10"
- Maximum height: standard shade - 192"; shade with cassette - 90"; shades with cordless spring roller - 96"
- Fabric will be railroaded when shade is wider than fabric width available (98"). Horizontal seams will be added on shades wider than 98" AND longer than 80" at factory discretion with seam placed as high as possible from the bottom of the shade unless otherwise specified. Regular and railroaded fabrics may appear different in appearance
- Shades over 94" width AND over 84" height will have a horizontal seem that will be placed as high as possible (from the bottom of the shade up)
- Minimum depth required for inside mount: 3/4" without cassette; 1 1/2" with cassette
- Depth required for inside flush mount: 3" without cassette; 4" with cassette
- Minimum flat space required for outside mount: 1 1/2"
- Continuous loop lift: cord length approximately 2/3 height of shade
- Reverse roll shades will have a large gap between the back of the window/wall and the fabric, increasing the amount of light around the edges of the shade.
- Please note: the optional cassette valance cannot be mounted at the sides. It must be mounted at the back or at the top of the cassette.
Options
- Cassette Valance - (adds 50%) - The optional cassette valance covers the roller at the top of the window and provides a clean, modern look.
- PLEASE NOTE: The cassette valance option must be ordered at the same time as the original shade and cannot be added after the shade is made.
- Standard Roll Orientation - Fabric rolls off the back of the roller (closest to the window).
- Reverse Roll Orientation - (adds $2) - Fabric rolls off the front of the roller (away from the window).
- Cordless Spring Roller - A spring hidden inside the metal roller tube allows for raising and lowering the shade by grasping the bottom hem.
- Chain Lift - A continuous loop beaded chain with tensioning mechanism is used to operate the shade. This lift type is required on shades over 73" wide.
See how Solar Shades are made
Questions & Answers
Options
- Cassette Valance - (adds 50%) - The optional cassette valance covers the roller at the top of the window and provides a clean, modern look.
- PLEASE NOTE: The cassette valance option must be ordered at the same time as the original shade and cannot be added after the shade is made.
- Standard Roll Orientation - Fabric rolls off the back of the roller (closest to the window).
- Reverse Roll Orientation - (adds $2) - Fabric rolls off the front of the roller (away from the window).
- Cordless Spring Roller - A spring hidden inside the metal roller tube allows for raising and lowering the shade by grasping the bottom hem.
- Chain Lift - A continuous loop beaded chain with tensioning mechanism is used to operate the shade. This lift type is required on shades over 73" wide.
See how Solar Shades are made
Measure & Install Instructions
Watch our How to Measure Video
Watch our How to Install Video
Inside Mount
- Mounted within the window frame
- Provides a clean, built-in look
- Great way to leave attractive woodwork exposed
- Minimum depth required for secure inside mount: 3/4"
- Depth required for inside flush mount: 3" without fascia: 4 1/4" with fascia
- If window frame isn't deep enough, please select outside mount
Outside Mount
- Great option when there is not enough depth for an inside mount
- Mounted to the wall, ceiling or molding surface surrounding the window
- Often used to make the window appear larger or to hide a less attractive window or door
- No minimum depth requirement
- Minimum of 1 1/2" flat surface (on wall, ceiling or frame) required for secure outside mount. Be sure to take into account the flat mounting surface area when measuring the area you want to cover with your shade. The factory will make the bracket to bracket width at the top of your roller shade to the width ordered. The fabric will be 7/8" to 1-3/8" narrower (based on the overall size of the shade) than the width ordered.
Measuring for Inside Mount
STEP 1: Measure the inside width the top of the window opening (where you will mount the shade). We will make the necessary deductions (approx. 1/8").
STEP 2: Measure the height at 3 locations - the left side, middle and right side. Record the largest of the 3 measurements. This is your ordering height.
NOTE: Solar shade fabrics will be approximately 7/8" to 1-3/8" narrower (varies by the size of the shade) than your ordering width to allow for brackets. If concerned over resulting light gap please select outside mount.
Measuring for Outside Mount
STEP 1: Measure the width of the area you wish to cover. If space allows we recommend adding 2-3" (1-1 1/2" each side) to this measurement to help eliminate light seepage. This is your ordering width and will be the overall measurement of the blind.
STEP 2: Measure the height of the area you wish to cover. This is your ordering height. Be sure to take into account the 1 1/2" flat mounting surface needed when measuring the area you want to cover with your shade. The factory will make your shade (including the roller at the top or the cassette valance, if ordered) to the height ordered. Generally 3" - 4" added to the height of your opening (including molding or framework you wish to cover) will allow you room to mount above the window frame.
NOTE: Solar shade fabrics will be approximately 7/8" to 1-3/8" narrower (varies by the size of the shade) than your ordering width to allow for brackets. If you need the fabric of your shade to cover a specific width (e.g. for mounting a shade on a door) add 1-3/8" inches to your ordered width to make sure you fabric is wide enough to cover your window opening.
How to Install Solar Shades with Spring Roller
Download Instructions
How to Install Solar Shades with Chain
Download Instructions
How to Install Solar Shades with Cassette Valence
Download Instructions
How to Install Solar Shades with Rollease Tension Device
Download Instructions
